TS605
24â€/600MM DYMODRILL
Application and Features
アプリケーションと機能
- Ideal machine for large diameter core drilling jobs.
- Normal Stand Column: 1106mm (43â€) with 634 mm (25â€) stroke.
- 73 mm (2-7/8â€) square column.
- Positive carriage lock.
Product Specification
| Model | TS605FS |
|---|---|
| Motor Model | H2531 |
| Power Rated (WATT) | 3,450 |
| No Load Speed (RPM) | 175 / 350 / 700 |
| Rated Load Speed (RPM) | 105 / 210 / 420 |
| Preferred Core Bit Dia. (MM) | 110 – 600 |
| Base Type | Fixed Anchor |
| Base Size (MM) | 230 x 400 |
| Column Height (MM) | 1106 |
| Travel Length (MM) | 634 |
| Weight (KG) | 65.1 |
